YASKAWA Control Sytem High Configuration Automatic Double Glass Sealing Machine
It can be upgraded according to customer's requirements
Main features:
- Sealing glue continuously for various sizes of rectangle insulating glass, and the quality is good.
- The special “V”synchronous conveyor, ensures the transmition steadily and no pollution.
- Detecting the size and thickness of the insulating glass automaticlly,adjusting the position of “V”conveyor accuratly and guarantees the same working height.
- Aiming at system and beautifying angle of glass automatically, ensures the insulating glass more aesthetic.
- Electric proportional valve regulates the pressure and hydraulic system control the sealant volume accurately
- Adopts the YASKAWA servo control system and man-machine interface operating system.
- Processing double glass and triple glass.
- Two groups of glue (polysulfide sealant and silicone sealant) can be exchanged automatically (optional).
- Equipped with glue quantity warning system, remind to change glue bucket.
Main technique parameter:
| Product model | WL2000-31 | WL2000-32 |
| Min.glass size | 350*500mm | 350*500mm |
| Max.glass size | 2000*2500mm | 2000*2500mm |
| Glass thickness | 3-12mm | 3-12mm |
| Sealant-mixing system | Single Sealant-mixingsystem | Two Sealant-mixing system |
| Insulating glass thickness | 12-56mm | 12-56mm |
| Sealing speed | 5-30m/min | 5-30m/min |
| Sealing width | 6-24mm | 6-24mm |
| Sealing depth | 2-15mm | 2-15mm |
| Conveyor speed | 0-48m/min | 0-48m/min |
| Power supply | 13KW | 13KW |
| Air supply | 0.5-0.8Mpa | 0.5-0.8Mpa |
| Working height | 520-580mm | 520-580mm |
| Dimension | 7850*3000*2950mm | 7850*3000*2950mm |
Main components:
| No. | Name | Brand | Country |
| 1 | Motion controller(MP2200) | YASKAWA | JAPAN |
| 2 | Servomotor(7series) | YASKAWA | JAPAN |
| 3 | Control module(IRO2310) | YASKAWA | JAPAN |
| 4 | Transducer | SCHNEIDER | FRANCE |
| 5 | Photoelectric switch | AUTONICS | KOREA |
| 6 | Approach switch | AUTONICS | KOREA |
| 7 | Low-voltage component | SCHNEIDER | FRANCE |
| 8 | Touch screen | SCHNEIDER | FRANCE |
| 9 | Pilot-operated type proportional flood valve | JILI | TAIWAN |
| 10 | Precise adjust pressure valve(five series) | SMC | JAPAN |
| 11 | Single -way valve | KOMPASS | TAIWAN |
| 12 | Air treatment | ATRTAC | TAIWAN |
| 13 | Air solenoid valve | AIRTAC | TAIWAN |
| 14 | Air cylinder | AIRTAC | TAIWAN |
| 15 | Liner guide rail | HIWIN | TAIWAN |
Kindly note:
Before you buy the machine, please make sure then tell me your local power supply,then we can make the right according to your true voltage.
FAQ:
1.Question:Are you a manufacturer?
Answer:
Yes,we are the professional insulating glass processing machines manufacturer, which has 16 years history since 2001.
2.Question: How about the service ?
Answer:
1).Reply it at once in WhatsAPP,if by email,it will be reply within 12 hours.
2).18 hours for after-sale serive
4).more than 15 years experience in this kind machine field
5).fluent english ,communication barrier free. Point-to-point service help you solve the problems timely.
3.Question:What’s the guarantee ?
Answer:
1). Our guarantee for 18 months.
2). 18 hours’ technical support by email, video or calling
3). English manual and video tutorial
4). 24 hours on line service each day, free professional technical support.
4. Q: Do you provide equipment operation training?
Answer:
A: Yes. We can will send one or two professional technicians (one is electrical engineer, one is mechanical engineer) to install and adjust the machines and help train the workers.
5.Question: Why your price isn't the lowest price compared with others company or factories ?
Answer:
1) We are a innovative enterprises, not only a produce factory. We have a a professional and experienced technical elite team. Every year we will apply for innovation patents for our insulating glass machine, likes auto gas filling machine, auto loading machine and etc.
2)Compared with the same level brand, we have the same functions and components, but our price is the most competitive. At the same time, our after sales service is satisfactory. We have a good reputation in our customers.
Packing and delivery:
1.Machine packing with plywood pallet or according to customers` requirements
2.In plywood pallet and plastic film
3.In container
Why Choose Us :
